| Specification |
|
| Monitor size | 15'' high resolution LCD display |
| Image display mode | B、2B、B+M、4B、M、B+Color、B+PDI、B+PW、PW、B+Color+PW、B+PDI+PW、B/BC Double real time |
| Supported probes | 1) 3.5C60U1: 3.5MHz/R60 Convex probe |
| 2) 7.5L40U1: 7.5MHz/L40mm Linear probe |
| 3) 6.5C15U1: 6.5MHz/R15 Micro-convex probe |
| 4) 6.5L64U1: 6.0MHz/L64mm Linear rectal probe |
| Full digital imaging technology | 1) Multi-beam synthesis |
| 2) Real-time point-by-point dynamic focus imaging |
| 3) Pulse Inversion Harmonic Composite Imaging |
| 4) Spatial Compounding |
| 5) Image enhancement and noise reduction |
| Imaging mode | 1) B mode |
| 2) M mode |
| 3) Color(Color Doppler ) mode |
| 4) PDI(Energy Doppler)mode |
| 5) PW(Pulse Doppler)mode |
| Supported frequency | 1) B/M: Fundamental frequency≥ 3 gear; Harmonic frequency≥ 2 gear |
| 2) Color/PDI：≥ 2 gear |
| 3) PW: ≥ 2 gear |
| Cineloop | 1) 2D mode, B Maximum: ≥6000 frames, Color, PDI Maximum: ≥2400 frames; |
| 2) Timeline mode(M, PW), Maximum: ≥ 190s |
| Image enlargement | Real-time scanning（B、B+C、2B、4B), Status: stepless enlargement |
| Image storage | 1) Support JPG, BMP, FRM image formats and CIN、AVI movie format; |
| 2) Support local storage; |
| 3) Support DICOM, meet the DICOM3.0 standard; |
| Built-in workstations: Support large-capacity hard disk(≥128G B), support patient data retrieval and browsing. |
| System language | 1) 8 kinds of languages: Chinese/English/French/German/Russian/Spanish/Czech/Ukrainian operating system and locales. |
| 2) Chinese and English annotation input in the image area, Chinese/ English; Chinese input methods ≥2, Wubi input method included |
| Measurement calculation software package | Abdomen, obstetrics, heart, blood vessels, small organs, etc. |
| Battery | Built-in high-capacity lithium battery, continue to work more than 1 hour, power information displayed on the screen. |
| Other functions | Annotation, puncture line, IMT automatic intimal measurement, report template, USB mouse support. |
|
|
| Configuration |
|
| Standard Configuration |
| Main unit(15 inch LCD monitor) | 1pc |
| 3.5MHz convex probe | 1 pc |
| 7.5MHz linear probe | 1 pc |
| Power adapter | 1 pc |
| Internal Li-battery | 1 pc |
| Power line | 1 pc |
| Handbag | 1 pc |
