| Bed frame | 30 × 60 × 1.5mm high-quality carbon steel pipe |
| Crossbeam | Cold-rolled steel pipe welded and formed |
| Bed welding | Smooth and flat, no burr, no exposed solder joint and no air bubble, high accuracy, stable and reliable |
| Bed plate | one-time formed cold-rolled steel sheet, with a thickness of 1.2 mm, four-section structure, can be easily disassembled, easy to clean and disinfect, and attached with steel pipe welding. The back plate support adopts double-rod support mode, and the
connection is stable. The bed panel has a porous design for easy ventilation. The mattress guard is mounted on the bed panel. |
| Casters and brake system | Stainless steel center-control pedal, the foot wheel is 125mm in diameter brake silent double-sided castors, easy to operate, smooth to push, high wear-resistant, no noise, good stability. |
| Cranket | ABS material, one-time injection molding. Built-in steel core, hidden design, foldable to 45 degrees. Crankets: two sets of high-quality crankets, which can adjust the patient's back and leg position flexibly. Overload protection device with two-way limit. 5, Dining table: Flip-down type ABS table board, with cup holder |
| functions | (1)Adjustment range of lifting/falling performance: The inclination of the back is 0 ° ~ 70º (+ 5º), and the inclination of the leg is 0 ° ~ 45º (+ 5º). (2) Surface spraying: Green environmental protection spraying treatment is adopted, the overall color is consistent, and the spraying is uniform. The bed is coated with electrostatic powder coating, anti-rust full-treatment paint, acid-base corrosion resistance and fading resistance. (3) Headboard: Adopt ABS blow molding, acid and alkali resistance, easy to clean. It can be easily and quickly disassembled, and can be used for CPR first aid. Equipped with patient information card slot.
(4) The bed head and end are provided with multi-functional sockets, and the side of the bed is equipped with telescopic multi-functional sockets, configured with a drip rack; There are four drainage frame hooks at the bottom of the bed. (5)Guardrail: With integral side guardrail, ABS blow molded integrally, hidden design, with hydraulic rod, gentle descent without
noise. Guardrail base: Aluminum alloy is cast to form and fixed on both sides of the bed. |
