| Main frame | 30 × 60 × 1.5mm high-quality carbon steel pipe.
|
| Crossbeam | Cold-rolled steel pipe welded and formed. |
| Bed welding | Smooth and flat, no burr, no exposed solder joint and no air bubble, high accuracy, stable and reliable. |
| Bed plate | 1.2 mm cold rolled steel sheet, four-section structure, which can be easily dismantled and easily cleaned and disinfected, The bed panel has a porous design for easy ventilation. |
| Casters | Universal rotary casters, diameter 125mm; aluminum alloy pedal, Four-wheel synchronous brake; The wheel surface is made of super polyurethane material, which is quiet and wear-resistant. It can be disinfected by water washing and high temperature. |
| Functions | (1) The bed body can be lifted as a whole by 650 (±5%) ~ 950 (±5%) mm (distance from the ground to the bed).
(2) Adjustable range of lifting performance: the back inclination is 0°~65º (+5º), the leg inclination is 0°~40º (+5º), and the front and rear inclination of the bed is 0-30º (+5º). The bed tilts 0-20º (+5º) left and right.
(3) With weighing function, the error is small ≤ 50g
(4) Information such as angle, weight and operating status displayed on the LCD screen.
(5) Surface spraying: It adopts green environmental protection spraying treatment, the overall color is consistent, and the spraying is even. The bed body is made of electrostatic powder coating, anti-rust fully treated paint, acid and alkali corrosion
resistance and fading resistance.
(6) Headboard: PE blow molding, acid and alkali resistance, easy to clean. It can be easily and quickly disassembled and can be used for CPR first aid. Equipped with patient information card slot.
(7) There is a multi-function slot at the head of the bed, which can be inserted into the infusion stand; there are four drainage hooks at the bottom of the bed.
(8) Guardrail: PE blow molding with segmented four-piece side guardrail, guardrail is equipped with operation control keys, lower hidden design, guardrail base: aluminum alloy die-casting, fixed on both sides of the bed, and rises and falls synchronously with the bed board. Equipped with manual panel and foot operation panel, it is convenient for patients and medical staff to operate and use. |
| Motor | (1) Brand: Jichang, 5 sets of silent motors, certified by safety standards, low noise; EMI electromagnetic compatibility guarantee, quiet and noiseless operation, does not interfere with the work of ventilators, ECG monitoring and other equipment.
Uninterruptible power supply system with energy storage function.
(2) Control current: maximum current 100mA, input voltage: 24V DC safe voltage; transmission: 24V DC, four sets of transmission are silent and noiseless. |
